| DR 3900 Benchtop Spectrophotometer Performance Specifications |
| 광학시스템 |
Split Beam |
| 측정모드 |
Transmittance (%), Absorbance, and Concentration |
| 광원 |
Tungsten Halogen |
| 파장 범위 |
320 to 1100㎚ |
| 파장 정확도 |
± 1.5㎚ (wavelength range 340-900㎚) |
| 파장 분해능 |
1㎚ |
| 파장 교정 |
자동 |
| 파장 선택 |
선택된 측정 프로그램에서 자동 |
| Scanning Speed |
= 8㎚/s (in steps of 1㎚) |
| Spectral Bandwidth |
5㎚ |
| 사용자 입력 프로그램 |
100 |
| 데이터 저장 |
2000 readings |
| 측정법 자동 인식 |
With TNTplus vial tests |
| 10-fold measurement and averaging |
With TNTplus vial tests (측정셀 표면을 10회 스캐닝하여 평균값 표시) |
| Physical and Environmental |
| 제품 크기 |
350×255×151㎜ (W×D×H) |
| 사용 조건 |
10 - 40℃ (50 - 104℉), max. 80% relative humidity (non-condensing) |
| 보관 조건 |
-40 - 60℃(-40 - 140℉) max. 80% relative humidity (non-condensing) |
| Additional Technical Data |
| 전원 |
Input: 100-240V/50-60 Hz (Output: 15 V/30 VA) |
| 입출력 지원 |
2×USB type A, 1×USB type B, 1×Ethernet |
| Enclosure rating |
IP40 (excluding interfaces and power supply) |
