| Speed range |
1RPM-600RPM, Positive and Negative |
| Speed adjustment resolution |
1RPM |
| Control method |
Film button, Touch screen, Mobile phone APP,, External analog signal
control, Dosing gun,, External R485/CAN communication control |
| External analog signal mode |
4-20mA, 0.5-5V, 1-10V, 1kHz-10kHz optional |
| Display mode |
4.3 inch industrial touch screen
Speed display, Flow rate display, Flow display |
| Power off memory function |
Support |
| Fast full speed function |
Support |
| Working mode |
Continuous mode, Distribution mode, Copy mode |
| Support functions |
On and Off ,Forward and Reverse, Speed control, Status memory, etc. |
| Flow Rate |
≤6000ml/min |
| Power |
<75W stepping version <150W servo version |
| Applicable power supply |
85~264VAC |
| Protection class |
Ip55 |
| Controller size |
306*183*252 |
| Weight |
7.5Kg |
