Size/nominal width |
|
3 foot (0.9 m) |
4 foot (1.2 m) |
6 foot (1.8 m) |
Dimensions |
Exterior dimensions W x H x D |
mm/in |
1000 x 1568 x 805 39.4 x 61.8 x 31.7 |
1300 x 1568 x 805 51.2 x 61.8 x 31.7 |
1900 x 1568 x 805 74.8 x 61.8 x 31.7 |
Interior dimensions W x H x D |
mm/in |
900 x 780 x 630 35.4 x 30.7 x 24.8 |
1200 x 780 x 630 47.2 x 30.7 x 24.8 |
1800 x 780 x 630 70.9 x 30.7 x 24.8 |
Shipping dimensions |
mm/in |
1372 x 1727 x 1168 54 x 68 x 46 |
1575 x 1727 x 1168 62 x 68 x 46 |
2261 x 1727 x 1168 89 x 68 x 46 |
Working height of front window |
mm/in |
Choice of 203 mm (8 inches) or 254 mm (10 inches) |
Maximum opening height of front window |
mm/in |
432 mm (17 inches) |
Weight |
Net weight |
kg/lbs |
169 (372) |
193 (426) |
272 (599) |
Shipping weight |
kg/lbs |
262 (577) |
297 (654) |
400 (880) |
Electrical data |
Voltage |
V |
Choice of 120 or 230 |
Frequency |
Hz |
50 / 60 |
Filter specification |
H14 HEPA EN 1822, 99.995% @ MPPS |
Certification |
NSF/ANSI 49, cULus, CE |
Ergonomics |
Lighting Power |
fc (lx) |
80-110 (850-1200) |
90-120 (950-1300) |
SmartPort |
Two 3 inch (80 mm) diameter user-modified pass-through cable ports, one on each side wall |
Receptacles |
120 V |
2 GFI protected duplex - left and right side |
230 V |
2 single receptacles - left and right side |
Service Valves |
Up to 6 total (3 on each side wall) |
8-inch (203 mm) front opening |
Sound pressure level |
dB (A) |
≤ 65 |
Energy consumption, operating set point |
W |
150 |
180 |
360 |
Energy Night Standby |
W |
70 |
70 |
120 |
Heat output operating |
BTU/hr |
512 |
614 |
1228 |
Heat output Night Standby |
BTU/hr |
239 |
239 |
410 |
Exhaust /inflow air volume |
cfm (m³/h) |
207 (351) |
276 (468) |
413 (702) |
Exhaust volume, thimble ducted |
cfm (m³/h) |
270 (460) |
360 (610) |
540 (910) |
10-inch (254 mm) front opening |
Sound pressure level |
dB (A) |
≤ 65 |
Energy consumption, operating set point |
W |
170 |
190 |
335 |
Energy consumption, night set-back mode |
W |
70 |
70 |
120 |
Heat output, operating mode (non-vented) |
BTU/hr |
580 |
648 |
1143 |
Heat output, night set-back mode (lights off, non-vented) |
BTU/hr |
580 |
648 |
1143 |
Exhaust /inflow air volume |
cfm (m³/h) |
258 (439) |
344 (585) |
517 (878) |
Exhaust volume, thimble ducted |
cfm (m³/h) |
335 (570) |
445 (760) |
670 (1140) |
